Samson 3374 - Preparation for Installation

EB 8331-3 EN 5-17
Installation
5.6 Electrical connection
Risk of fatal injury due to electric shock.
Î Upon installation of the electric cables,
you are required to observe the regula-
tions concerning low-voltage installations
according to DINVDE0100 as well as
the regulations of your local power sup-
plier.
Î Use a suitable voltage supply which
guarantees that no dangerous voltages
reach the device in normal operation or
in the event of a fault in the system or
any other system parts.
Î Only perform the electrical connection
after switching off the supply voltage.
Make sure the supply voltage cannot be
switched on again unintentionally.
Î Connect the wiring as shown in
Fig.5-19.
Î Guidethecablestothespring-cageter-
minals from the top.
After applying the supply voltage, the actua-
tor is ready for use.
A maximum of three cable glands can be
mounted to the housing for cable entry.
DANGER
!
Note
