15.1 Parts for retrotting and accessories
Parts for retrotting
Basicunitforlimitcontactsand/orresistancetransmitters Orderno.1400-8829
Mechanical limit contacts Orderno.1402-0898
Resistance transmitter Refer to Table 15-1
GearwheelforresistancetransmitterPCB Orderno.1992-5885
Accessories
V2001 mounting kit Orderno.1400-9515
Spacer to mount the actuator on Type 3323 Valve (DN 65 to 80) Order no. 0340-3031
SetwiththreecableglandsM20x1.5withmetalnut(SW23/24) Order no. 1400-8828
Table 15-1: Resistance transmitters · Selecting the actuator board
1)
Type 3374 -10 -11 -15 -17 -21 -26 -31 -36
Supply voltage
230V/50Hz
Standard Orderno.1180-9601 Orderno.1180-9607
Faster motor Orderno.1180-9604 – Orderno.1180-9610
230V/60Hz
Standard
Orderno.1180-9637 – Orderno.1180-9643
24V/50Hz
Orderno.1180-9603 Orderno.1180-9609
Faster motor Orderno.1180-9606 – Orderno.1180-9612
24V/60Hz Standard Orderno.1180-9639 – Orderno.1180-9645
1)
Forretrot,additionallytwogearwheels(orderno.1992-5885)necessary
