20 EB 6116 EN
Design and principle of operation
Wall and pipe mounting·Order no. 1400-6216
Ø40
88
127
EXHAUST(venting)
IP65
M20x1.5 or ½-14 NPT
for electrical connection
Pressure gauge
SUPPLY
OUTPUT
Wall mounting
72
118.4
OUTPUT
Cable gland
EXHAUST
(venting)IP65
75
220
Ø 2" pipe
15
OUTPUT
Clamp for attachment
to 2“ pipe
Wall
mounting
SUPPLY
Fig.6: Dimensional drawings for wall and pipe mounting
