The illustrations on these two pages show the
required interconnections when using the SX Series
in Stereo, Bridge and Parallel modes. Wiring for
Speakon™ connectors (shown on the right) is indi
-
cated where appropriate.
SX Series Connections
+-
-+
(4 ohm min)
(4 ohm min)
MPL2242
MMPL2242
+-
-+
(4 ohm min)
(4 ohm min)
+
-
-
+
+
-
+
-
(8 ohm min)
(8 ohm min)
(8 ohm min) (8 ohm min)
MPL2242
MMPL2242
+-
(8 ohm min)
MPL2242
MMPL2242
Speakon™ wiring:
1- 1+
2+ 2-
NOT CONNECTED
NOT CONNECTED
Stereo Mode: (two or four speakers)
Bridge Mode: (single speaker only)
(4 ohm min)
+-
ENGLISH
