Appendix A Outdoor GPS Antenna Installation
Verizon 4G LTE Network Extender 2 User Guide v1.1 63
Copyright © 2017, All Rights Reserved.
Wall Mount GPS Antenna
Figure 32. GPS Antenna Installation (Wall)
GPS Antenna Wall Fixing
Pipe (Ф25.4 mm)
GPS Antenna
Bakelite
GPS Antenna Clamp
GPS Antenna
Wall Fixing Clamp Assembly
≒
Min. 500 mm
