3-4 VGA EDID table
Details:
3 Alignments and Adjustments
3-2
0123 456789ABCDEF
000FFFFFF FFFFFF 004C2D2B 02XXXXXXXX
1XXXX0103 6C221B782ADC55A359489E24
2115054BFEF808180714F814001010101
301010101 0101302A009851002A403070
41300520E1100001E000000FD00384B1E
5510E000A202020202020000000FC0053
6796E634D61737465720A2020000000FF
700XXXXXX XXXXXXXXXXXXXX0A 20 20 00CS
Byte(Hex) Field Name and Comments Description EDID
00-07(8 byte) Head Information 00,FF,FF,FF,
FF, FF, FF,00
08--09 ID Manufacturer Name SAM 4C,2D
0A--0B Product ID Code 022B 2B,02
0C--0F Last 5 Digits of Serial Number Used Notes1 XX,XX,XX,XX
10 Week of Manufacture Notes2 XX
11 Year of Manufacture Notes3 XX
12 EDID Version Number 1 01
13 EDID Revision Number 3 03
14 Video Input Definition Analog Signal 6C
0.700,0.000(0.700Vpp)
Separate Sync
Composite Sync
15 Max Horizontal Image Size (cm) 34 22
16 Max Vertical Image Size (cm) 27 1B
17 Display Gamma 2.2 78
18 Power Management and Active Off 2A
Supported Feature(s) Display Type = R/G/B Color
Preferred Timing Mode
19-22 (10 byte) Chroma Info Red X - 0.640, Red Y - 0.349, DC,55,A3,59,
Green X - 0.284, 48,9E, 24,11,
Green Y - 0.617, 50,54
Blue Y - 0.067, Blue X - 0.142,
White X - 0.313,
White Y - 0.329
23 Established Timing I 720x400@70Hz BF
720x400@88Hz(no)
640x480@60Hz
640x480@67Hz
640x480@72Hz
640x480@75Hz
800x600@56Hz
800x600@60Hz
To Next Page
