3 Alignments and Adjustments
3-3
Remark:
Notes1: Get SerialNumber(10----14Digit) from BarCode and transfer it to HEX
Notes2: Week(1---53),
Notes3: Year , HEX(Year-1990) ,
Notes4: Get Barcode(5----14Digit), and save as ASCII
Byte(Hex) Field Name and Comments Description EDID
24 Established Timing II 800x600@72Hz EF
800x600@75Hz
832x624@75Hz
1024x768@87Hz (no)
1024x768@60Hz
1024x768@70Hz
1024x768@75Hz
1280x1024@75Hz
25 Manufacturers Reserved Timings Support 80
26-35 (16 byte) Standard Timing Identification 1280x1024@60Hz81,8071,4F 81,80
1152x864@75Hz 81,40
1280x960@60Hz 01,01
Not Used 01,01
Not Used 01,01
Not Used 01,01
Not Used 01,01
Not Used
36--47 (18 byte) Detailed Timing / 1280X1024@60HZ 30,2A,00,98,
Descriptor Block 1 Pixel Clock:108.00MHZ 51,00,2A,40,
30,70,13,00,
52,0E,11,00,
00,1E
48-59 (18 byte) Detailed Timing / Descriptor Monitor Range Limits:
Block 2 Min Vertical Freq - 56 Hz 38
Max Vertical Freq - 75 Hz
Min Horiz. Freq - 30 KHz 4B
Max Horiz. Freq - 81 KHz
Pixel Clock - 140 MHz 1E
Secondary GTF - Not Supported 51
0E
00
5A-6B (18 byte) Detailed Timing / Descriptor Monitor Name: 53,79,6E,63,
Block 3 SyncMaster 4D,61,73,74,
65,72
6C-7D (18 byte) Detailed Timing / Descriptor Serial Number: Notes4 XX,XX---
Block 4 XX,XX
7E Extension flag 00
7F Checksum CS
