Disassembly and Reassembly _ 11
Part Figure Description
Sub and Main PCB
Assembly
6. Removethe5xingscrewsonbackwardand
2xingscrewsonfrontward.
7. Separatethehooks(LeftsideandRightside)
and Separate the Assy panel upward.
 Becarefuldamageofhooks.
8. Removethe4xingscrewsandSeparate
the cover pcb(s) and the wires connected to
the sub PBA.
Water Valve
1. Afterseparatingthecontrolpanel,separate
the water-valve housing.
2. Removethe3xingscrews.
3. Remove the wire-harness and release the 2
clamps connecting the hoses.
 Whenreleasingtheclamps,takecare
that you do not tear the hoses.
