Samsung A50K8600A/A2 Series - Door Assembly

12 _ Disassembly and Reassembly
Part Figure Description
Door Assembly
1. Remove the 4 screws and Separate Holder
Damper(left,right).
2. Removethe4screwsonHingeleft,right.
3. Remove the 2 screws on downward of Cover
Top.
4. Separate Assy Door upward.
