Disassembly and Reassembly
Samsung Electronics 3-19
No. Parts Procedure Remark
10
Bracket Motor
1) Remove the 2 screws from the
Bracket Motor and separate it.
(Use +Screw Driver)
11 Base Heater 1) Remove 4ea pf screws from the Base
heater and separate it.
(Use + Screw Driver)
2) Seperate the Base heater Wire con-
nector from the Outdoor Unit Control
Part.
To Next Page
