Disassembly and Reassembly

Samsung Electronics 3-51

No Parts Procedure Remark

Motor & Blower

1) Disassemble the Cabinet Top Motor.

- Unscrew 8 screws

2) Disassemble the Cover Blower Upper

with pushing its hook.

3) Disassemble the Cover Control.

- Unscrew 2 screws

■AC026RNLDKG/AC035RNLDKG
