PCB Diagram and Parts List
Samsung Electronics 5-29
5-2-3 EMI PBA
■ AC100/120/140RXADKG
①
#1 : AC POWER(N)
②
#1 : AC POWER(L)
③
#1 : AC POWER(L)
#3 : AC POWER(N)
④
#1 : AC POWER(N)
⑤
#1 : AC POWER(L)
CN301 : FAN MOTOR
CN4 : AC POWER(L)
CN461 : SW DOWNLOAD CN701 : POWER CN5 : AC POWER(N)
1
4
5
3
2
