Samsung AC100RN4PKG User Manual

PCB Diagram and Parts List
5-28 Samsung Electronics
■ AC052/071RXADKG
①
#1: RXD
#2: TXD
#3: DC5V
#4: GND
#5: DC12V
#6: POWER CTRL
#7: AC LOAD
#8: AC LOAD2
②
#1: N
#2: -
#3: L
③
#1~4: ECO DOWNLOAD
④
#1: DC310V
#2: -
#3: PGND
#4: DC15V
#5: V_SP
#6: F/B
⑤
#1: L / RELAY CONTACT
#2: -
#3: N
⑥
#1: N
⑦
#1: EARTH
⑧
#1: L
⑨
#1~7: ECO COMM port
⑩
#CN401: U, RED
#CN402: V, BLU
#CN403: W, YEL
⑪
#CN501,052: REACTOR
⑫
#1~20: DOWNLOAD
CNP351-MAIN INV
CN241-HOT GAS (AC LOAD)
CN581-ECO COMM
CN030-MAIN POWER
CN001-N / TAP TERMINAL
CN401, 402, 403-COMP
CN571-ECO DOWNLOAD
CN571- EARTH TAP
TERMINAL
CN051, 052-REACTOR
CNP901- BLDC FAN
CN002-L / TAP TERMINAL
CN551-DOWNLOAD
This Document can not be used without Samsung’s authorization.
1
2
3
4
5
6
7
8
9
12
11
10
