Samsung AC100RN4PKG User Manual

PCB Diagram and Parts List
Samsung Electronics 5-27
This Document can not be used without Samsung’s authorization.
①
#1 : RXD
#2 : TXD
#3 : DC5V
#4 : GND
#5 : DC12V
#6 : POWER CTRL
#7 : 4WAY(AC LOAD)
#8 : -
②
#1 : N
#2 : -
#3 : L
③
#1 : RXD_INV
#2 : TXD_INV
#3 : GND
#4 : DC5V
④
#1 : DC310V
#2 : -
#3 : GND
#4 : DC15V
#5 : V_sp
#6 : F/B
⑤
#1 : L
⑥
#1 : EARTH
⑦
#1 : N
⑧
#1~#7 : ECO COMM PART
⑨
#1 : W Phase
#2 : V Phase
#3 : U Phase
⑩
#1 : REACTOR
⑪
#1~#20 : DOWNLOAD
CN351 - MAIN INV. COMM CNP031 – MAIN POWER CNP552 – ECO DOWNLOAD CNP901
CNP001 – L / TAP
TERMINAL
CNP401 – COMP
CNP003 – EARTH / TAP
TERMINAL
CNP051,CNP052 –REACTOR
CNP002 – N / TAP
TERMINAL
DOWNLOAD
CNP361 – ECO DOWNLOAD
