Product Specifications

Samsung Electronics 2-7

Features (Wind-Free 4Way CST) (cont.)

■ ENoBackFlowingDrainWater

Check Valve on the drain pump prevents drain water from reversing



■ EasyMaintenance

Easy Air Flow Blade Cleaning

Company A

SAMSUNG

Dirty

Drain Board

Check Valve :

Prevents drain

water from

reversing

Clean

Drain Board
