Disassembly and Reassembly

Samsung Electronics 3-13

No Parts Procedure Remark

3) Remove the screw of the Cover Pipe

that is used to fix the In/Out Pipe.

Remove the In/Out Pipe.

(Use +Screw Driver)

4) Remove the Heat Exchanger from the

indoor unit’s cabinet.
