Product Specications

Samsung Electronics 2-11

Structure of product (Heat Pump AMSSSKXS Series)

AM240/260/280KXVGSS, AM240/260/280/300KXVASS, AM080KXVSSS

Heat Exchanger

Compressor

CONTROL BOX

4-WAY V/V

Subcooler

Gas Pipe

Liquid Pipe
