Product Specications

Samsung Electronics 2-13

2-1-8 Structure of product (Cooling only AMSSSMXVAGC Series)

AM140/160MXVAGC

Control Box

Liquid V/V

Gas V/V

Subcooler

Accumulator

Heat

Exchanger

AM080/100/120MXVAGC
