Samsung AM240MXVGNR/ET - Page 211

PCB Diagram and Parts List
Samsung Electronics 5-7
ASS'Y PCB MAIN-HUB
(cont.)
Ŷ DC (cont.)
①
CN714CCH1
②
CN715MAINCOOLING
③
CN713CCH2
④
CN704HOTGASVALVE1
#1 : CCH1
#2 : CCH1
#1: MAINCOOLING
#2: MAINCOOLING
##1 : CCH2
#2 : CCH2
#1 : HOTGAS BYPASS1
#2 : HOTGAS BYPASS1
⑤
CN705HOTGASBYPASS2
⑥
CN703EVIBYPASS
⑦
CN716ODEEVVALVE
⑧
CN711OILRETURNVALVE
#1:HOTGAS BYPASS2
#2:HOTGAS BYPASS2
#1 : EVI BYPASS1
#2 : EVI BYPASS1
#1: OD EEV VALVE
#2: OD EEV VALVE
#1 : ACCUM OIL RETURN VALVE
#2 : AC CUM OIL RETURN VALVE
⑨
CN708 4WAYVALVE
⑩
CN70AC POWER INPUT
⑪
CN701 EVI VALVE 1,2
#1 : 4WAY VALVE
#2 : 4WAY VALVE
#1 : AC LIVE
#2 : AC NEUTRAL
#1: EVI VALVE 1
#3: EVI VALVE 2
#7: EVI VALVE 1
#8: EVI VALVE 2
#9: AC NEUTRAL
