Disassembly and Reassembly

Samsung Electronics 3-9

ـ Comp Wire fix by

Holder Wire.

ـ Fix Comp Wire-Core to

Bracket Beam Control

Box using large size

Cable Tie(350mm).

ـ Separate double layer structure of C/Box after remove 3 screws and

connector.

Binding Wire 3

AM080/100/120

666
