[Reference Sheet]
Pipe Welding Position
غ
AM080/100/120MXVA
6
C
Front Welding Parts Rear Welding Parts
5
9
8
7
4
1
3
2
6
10
11
8
9
6
7
5 3
2
4
1
10
No. Welding Position Q'ty No. Welding Position Q'ty
1 Comp+Suction 1 1
Cooling+Subcooler
1
2 Comp+Discharge 1 2
Subcooler+EVI Bypass
1
3 Comp+Vapor Injection 1 3
Accum+Service Valve
1
4 Discharge+Oil Sepa 1 4
Accum+Accum Oil Vavle
1
5 Cond Connector+Oil Sepa Out 1 5
Accum+EVI Bypass
1
6 Oil Return+Suction 1 6
Vapor Injection+EVI Bypass
1
7 Hot Gas Vavle +Suction 1 7
Hot Gas Vavle +Oil Sepa Out
1
8 Expansion+Subcooler 1 8
Cond Connector+Cond In
1
9 Pinch Pipe 1 9
Expansion+Cond Out
1
10 Accum Oil Return Valve + Suction 1
10
Liquid Ball Vavle +Cooling
1
11 Accum+Suction 1
