Disassembly and Reassembly

3-20 Samsung Electronics

Binding Wire 3

AM140JXV

666

ـ Comp Wire fix by Holder

Wire.

ـ Fix Comp Wire-Core to

Bracket Beam Control

Box using large size Cable

Tie(350mm).

ـ Separate double layer structure of C/Box after remove 3 screws and

connector.
