Samsung Electronics
Exploded Views and Parts List
5-2
Parts List
No. Code No. Description Specification
Q’TY
SA/SNA
AQV18VBCN AQV24VBCN
1 DB92-01086G ASSY PANEL FRONT ASS’Y 1 1 SA
1-1 DB64-01638A PANEL FRONT HIPS
1 1 SA
1-2 DB63-01594B FILTER PRE PP
2 2 SA
1-3 DB64-01639A PANEL MID HIPS
1 1 SNA
1-4 DB66-01152A LINK GRILLE POM
1 1 SNA
1-5 DB66-01156A GEAR RACK POM
1 1 SNA
1-6 DB66-01155A GEAR PINION POM
1 1 SNA
1-7 DB31-00369B ASSY MOTOR STEPPING
220-240V~, 50/60Hz,
Class E
1 1 SA
1-8 DB61-03156A HOLDER WIRE PC 3 3 SNA
1-9 DB66-01176A LINK SUPPORT POM
4 4 SNA
1-10 DB61-03139C SPRING GRILLE STS304
2 2 SNA
1-11 DB63-01630A COVER DISPLAY ABS
1 1 SNA
1-12 DB93-04452F ASSY DISPLAY ASS’Y
1 1 SA
1-13 DB61-02913A FRAME GRILLE HIPS
1 1 SA
1-14
DB92-01202D ASSY WINDOW MIRROR
ACRYL
1 1 SA
DB61-02913A ASSY WINDOW GRILLE
- - SA
2 DB94-01245A ASSY TRAY DRAIN ASS’Y 1 1 SA
2-1 DB63-01581A TRAY DRAIN ABS
1 1 SNA
2-2 DB61-02914A BLADE H HIPS
1 1 SA
2-3 DB61-01976A BLADE V PP
2 2 SA
2-4 DB73-00180A RUBBER CAP DRAIN GUM-EPM
1 1 SNA
2-5 DB94-00458B ASSY DRAIN HOSE ASS’Y
1 1 SA
2-6 DB31-00370A MOTOR STEP
220-240V~, 50/60Hz,
Class E
1 1 SA
3 DB63-01063C COVER TERMINAL ABS V0 1 1 SA
4 DB63-01065A COVER BEARING ABS 1 1 SNA
5 DB96-03817A ASSY EVAP SUPPORT ASS’Y 1 1 SA
6 DB93-05869A ASSY CONTROL IN ASS’Y 1 1 SA
7 DB90-02082A ASSY COVER PCB ASS’Y 1 1 SNA
8
DB96-06587E
ASSY EVAP TOTAL
ASS’Y
1 - SNA
DB96-06587F
- 1 SNA
9 DB67-60030A SPRING SENSOR STS304 1 1 SNA
10 DB94-00455A ASSY BEARING RUBBER ASS’Y
1 1 SNA
11 DB94-00456B ASSY CROSS FAN ASS’Y
1 1 SA
12 DB31-00267A MOTOR FAN IN
220-240V~, 50/60Hz,
Class E
1 1 SA
13 DB94-01153B ASSY BODY BACK ASS’Y 1 1 SA
13-1 DB61-03029A BODY BACK HIPS
1 1 SNA
13-2 DB93-04230A ASSY COMPACT MPI ASS’Y
1 1 SA
13-3 DB63-01583A COVER MPI HIPS
1 1 SNA
14 DB61-01981B HOLDER PIPE HIPS
1 1 SNA
15 DB67-00499C CAP SCREW HIPS
3 3 SNA
16 DB70-00505A PLATE HANGER SGCC-M
1 1 SNA
18 DB93-04700P ASSY REMOCON ARH-1346
1 1 SNA
To Next Page
