Samsung Electronics
9-2 Refrigerating Cycle Diagram
9-3
Heat
Exchanger
(Evaporator)
Heat
Exchanger
(Condenser)
Propeller Fan
Cross Fan
2 way valve
3 way valve
4 way valve
Gas side
Liquid side
Compressor
Indoor Unit Outdoor Unit
Cooling
Heating
Gas Leak Check Point
Expansion valve
