Samsung Electronics
5-3 Ass'y Control In : DB93-05869A
5-5
Parts List
No. Code No. Description Specification Q’ty SN/SNA
1 DB61-02912A CASE-CONTROL ABS 1 SA
2 DB65-00004U TERMINAL BLOCK ASSY 1 SNA
3 DB93-05620B ASSY MAIN PCB ASSY 1 SA
4 DB39-01210B C/W POWER(N) ASSY 1 SNA
5 DB70-00507A PLATE TERMINAL LOW SGCC-M T1.2 1 SNA
6 DB61-01097A HOLDER WIRE CLAMP ABS 1 SNA
7 6001-000929 SCREW MACHINE PH M3*L22 1 SNA
8 6001-001054 SCREW MACHINE TH M4*L10 3 SNA
9 DB93-04832A C/W STEP MOTOR UP/DOWN ASSY 1 SNA
10 DB32-00020E ASSY THERMISTOR 4P (103T)
1 SA
11 DB39-01193A COMM 485 WIRE ASSY
1 SNA
12 DB39-00765T C/W POWER(L) LEAD WIRE
1 SNA
13 DB93-04622A C/W DISPLAY 15P
1 SNA
14 DB93-04430A ASSY MODULE PCB ASSY
1 SNA
15 DB93-04484A C/W STEP MOTOR AUTO GRILL 5P
1 SNA
16 DB93-04695A C/W MPI 4P (103T)
1 SNA
To Next Page
