Samsung Electronics
The red number connecter is not used.
Power Temperature Sensor
Motor RPM Feedback Auto Grill
Remocon Module HVPS(High voltage Generator)
Humidity Sensor BLADE-H Step Motor
Anions
Display
MPI Indoor Fan Motor
7
8
9
1
2
3
4
5
10
11
12
10. PCB Diagram
10-1 Indoor PCB
10-1
1
11
12
8
7
2
3 4
9
10
6 5
6
