Exploded Views and Parts List
 Parts List
No. Code No. DESC_SPEC PARA1 PARA2
AQV18VBCX AQV24VBCX
SA/SNA
DB93-05539E DB93-05539F
1
DB93-05544E ASSY-PCB OUT ASSY PCB-OUTDOOR AQV18VBCX
1 - SNA
DB93-05544F ASSY-PCB OUT ASSY PCB-OUTDOOR AQV24VBCX
- 1 SNA
2
DB93-04267C ASSY-PCB EMI ASSY PCB-OUTDOOR M2/F2/V2 - 24K
- 1 SNA
DB93-04267D ASSY-PCB EMI ASSY PCB-OUTDOOR M2/F2/V2 - 18K
1 - SNA
3 DB93-04329A ASSY PCB DISPLAY ASSY PCB DISPLAY 24K/18K(SUB) 1 1 SNA
4
2301-001369 C-FILM,LEAD-OTHER 3.0uF 450V
1 - SNA
2301-001379 C-FILM,LEAD-OTHER 4.0uF 450V
- 1 SNA
5 DB93-04908D CONNECT WIRE
MAIN POWRE TO INDOOR
POWER
AWG #16
1 1 SNA
6 DB93-04337A CONNECT WIRE #2096 26 AWG - 1 1 SNA
7 DB93-04334B CONNECT WIRE C/W REACTOR * 1 1 SNA
8 DB62-05320A ASSY-INSULATOR MICA . KFR-35GW/WCI 1 1 SNA
9 DB91-00306A ASSY-SCREW MACHINE SCREW M3,L16 2 2 SNA
10 DB91-00307A ASSY-SCREW MACHINE SCREW M4,L16
5 5 SNA
11 DB61-02973A CASE CONTROL-BASE CASE CONTROL BASE
ABS V0, T2.0,
AS18BPBX
1 1 SNA
12 DB61-02974A CASE CONTROL-COVER CASE CONTROL COVER 1 1 SNA
13 DB61-02977A PLATE-CONTROL OUT PLATE-CONTROL OUT
AS18BPBX,
SGCC-M
1 1 SNA
14 DB61-02975A CASE-DISPLAY PCB CASE DISPLAY PBA ABS V0, T2.0
1 1 SNA
15 DB62-05315A HEAT SINK HEAT SINK AQV24AWA
1 1 SNA
16 DB61-00250A HOLDER WIRE CLAMP HOLDER-WIRE CLAMP
* 2 2 SNA
17 DB61-00206B HOLDER-WIRE HOLDER-WIRE
GALVA-
SBHG,BLK
1 1 SNA
18 DB62-04566B
INSULATION-CONTROL
BOX TOP
FOAM-LEX
2 1 1 SNA
19
6002-000234 SCREW TH + M4,L10
4 4 SNA
6003-000336 SCREW TH + M4,L10
2 2 SNA
20 6002-000630 SCREW PH + 2S,M3,L8
4 4 SNA
21 6009-001001 SCREW TH+ M4,L8
4 4 SNA
22 6002-000536 SCREW-TAPPING PH+ M4,2S
1 1 SNA
23 6002-000555 SCREW-TAPPING PH+ M4,2S,L25
1 1 SNA
24 6002-000231 SCREW-TAPPING THH+ M4,2S,L12
1 1 SNA
25
DB95-01078F ASSY-TERMINAL BLOCK ASSY-TERMINAL BLOCK
250 TAB 6pin
1 1 SNA
DB65-00228A TERMINAL BLOCK TERMINAL BLOCK
1 1 SNA
26 DB65-10088D CABLE-TIE NYLON66 L100MM
1 1 SNA
27 DB98-24813A ASSY THERMAL GREASE Unit : gram 0.002 0.002 SNA
28 DB95-01040G ASSY NOISE ABSORBER 100nF,275V
1 1 SNA
