Electrical Parts List
6-20
 OUTDOOR EMI PCB :DB93-04267A (AQV24VBC)
Location No. Code No. Description Specification Q’ty SNA/SA Remark
VA01 1405-000154 VARISTOR 460Vdc,2500A 1 SNA
VA02 1405-000154 VARISTOR 460Vdc,2500A
1 SNA
VA03 1405-000154 VARISTOR 460Vdc,2500A
1 SNA
VA05 1405-000154 VARISTOR 460Vdc,2500A
1 SNA
R002 2001-001150 R-CARBON(S) 470KOHM,5%,1/2W
1 SNA
R003 2001-001150 R-CARBON(S) 470KOHM,5%,1/2W
1 SNA
C004 2201-000154 C-CERAMIC,DISC 10NF,+80-20%,2KV
1 SNA
C005 2201-000154 C-CERAMIC,DISC 10NF,+80-20%,2KV
1 SNA
C009 2201-000540 C-CERAMIC,DISC 4.7NF,20%,2KV
1 SNA
C010 2201-000540 C-CERAMIC,DISC 4.7NF,20%,2KV
1 SNA
C003 2301-001285 C-FILM,LEAD-PPF 680NF,10%,275V
1 SNA
C007 2301-001285 C-FILM,LEAD-PPF 680NF,10%,275V
1 SNA
FUSE 3601-001381 FUSE-CARTRIDGE 250V,30A
1 SNA
FUSE CLIP 3602-001038 FUSE-CLIP 250V,30A,10mohm
2 SNA
L 3712-001139 CONNECTOR-TERMINAL TAB,MALE,-,6.35X0.8MM 1 SNA
N 3712-001139 CONNECTOR-TERMINAL TAB,MALE,-,6.35X0.8MM 1 SNA
DSA 4715-001093 SURGE ABSORBER 3600V,20%,2000A,-,AXIAL
1 SNA
FT00 DB27-00040A COIL CHOKE SSC3120030B,3.0mH,
1 SNA
FT01 DB27-00040A COIL CHOKE SSC3120030B,3.0mH,
1 SNA
PCB DB41-00531A PCB SUB FORTE,CEM-3,2,1.0,1.6T,160*140
1 SNA
C/W POWER DB93-05058A ASSY CONNECTOR WIRE WIRE
1 SNA
