30
NO. Parts Procedure Remark
10) Please allign the wire such as
picture if you re-assemble after
separate connector w ir e .
If the connector is excessively
folded,thereisariskofre.
11) Please remove the CABINET
SIDE upward direction.
2
FAN & MOTOR 1) Please Loosen the NUT 1ea
clockwise.
(Using MONKEY SPANNER)
2) Please remove the HOUSING’s
MOTOR
WIRE.
To Next Page
