Samsung AR09TXFYAWKNEU - Electrical Parts List; 6-1 Indoor Main PCB Parts

36
6-1 INDOOR MAIN PCB CODE DB92-04839A
Parts Code Design Loc Parts Description Spec. Quantity Unit
0201-001528 COATING ADHESIVE-SIL LDC2577D,Y/GRN,175CPS 3.3 G
0201-001982 ADHESIVE-SIL ADHESIVE-SIL TSE3854DS-W,White,2.2,MIL-A-46146B,UL94V-0 0.0035 KG
0202-001463 SOLDER-WIRE SOLDER-WIRE LFC2-W3.0,D3,99.79Sn/0.2Cu/0.01P,No Flux 4.2 G
0202-001608
SOLDER-WIRE
FLUX
SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0.7Cu/0.01P,Flux 3.5% 2.4 G
0204-005794 SOLVENT SOLVENT S-1000,(CH3)2CHOH,100%,0.79 1.2 G
0402-000324 BD100 DIODE-BRIDGE D3SB60,600V,4A,SIP-4,ST 1 PC
1203-002722 REG900 IC-POSI.FIXED REG.
KA78R15,TO-220,4P,10x15mm,PLASTIC,14.6/15.4V,1.
5W,-20to+80C,ST
1 PC
1203-009020 PW100 IC-PWM CONTROLLER
TOP253P,DIP,7P,6.35x9.57mm,PLASTIC,-
0.3/700V,15W,-40to+150C,1.37A,ST
1 PC
1404-001194 PTC320 THERMISTOR-PTC
39ohm(Typ),270VAC,1.2A,RADIAL(DISC),0.2A,11x5
mm,TP
1 PC
1404-001413 NTC100 THERMISTOR-NTC
18ohm,3A,3200K,19MWC,15mm,TP,17x6mm,RADIA
L(DISC)
1 PC
1405-000160 VA100 VARISTOR 680V,560VDC,4500A,17.5x8mm,TP,1120V,500pF,D14 1 PC
2201-002688 C104 C-CERAMIC,DISC 2.2nF,20%,400Vac,Y5U,TP,12.5x7mm,10mm 1 PC
2201-002688 C105 C-CERAMIC,DISC 2.2nF,20%,400Vac,Y5U,TP,12.5x7mm,10mm 1 PC
2201-002688 C112 C-CERAMIC,DISC 2.2nF,20%,400Vac,Y5U,TP,12.5x7mm,10mm 1 PC
2201-002688 C113 C-CERAMIC,DISC 2.2nF,20%,400Vac,Y5U,TP,12.5x7mm,10mm 1 PC
2301-002032 XC100 C-FILM,LEAD-PPF 100nF,10%,275Vac,TP,12.5x6x12mm 1 PC
2401-003139 CE104 C-AL 1000uF,20%,25V,WT,TP,10x20mm,5mm 1 PC
2401-004393 CE103 C-AL 100uF,20%,500V,BK,25.4x30mm,10mm 1 PC
3002-001129 BZ600 BUZZER-PIEZO 85dB,2KHz,BK 1 PC
3601-001336 F101 FUSE-AXIAL LEAD 250V,3.15A,TIME-LAG,CERAMIC,5.2x20mm 1 PC
3711-000260 CNP100 HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92mm,STRAIGHT,SN,BLU 1 PC
3711-000296 CN900 HEADER-BOARD TO CABLE 1WALL,6P,1R,3.96MM,STRAIGHT,SN,WHT 1 PC
3711-000880 CN320 HEADER-BOARD TO CABLE BOX,3P,1R,2.5MM,STRAIGHT,SN,RED 1 PC
3711-002001 CN230 HEADER-BOARD TO CABLE
BOX,20P,2R,2.0mm,STRAIGHT,SN,BLK,5.0X22.0X6
.6mm
1 PC
3711-004122 CN340 HEADER-BOARD TO CABLE BOX,14P,1R,2mm,STRAIGHT,SN,WHT 1 PC
3711-004484 CN800 HEADER-BOARD TO CABLE BOX,5P,1R,2mm,STRAIGHT,SN,WHT 1 PC
3711-005096 CN801 HEADER-BOARD TO CABLE BOX,5P,1R,2MM,STRAIGHT,SN,BLK 1 PC
3711-005097 CN810 HEADER-BOARD TO CABLE BOX,5P,1R,2MM,STRAIGHT,SN,BLU 1 PC
3711-005098 CN390 HEADER-BOARD TO CABLE BOX,5P,1R,2MM,STRAIGHT,SN,RED 1 PC
3711-009520 CN100 HEADER-BOARD TO CABLE
BOX,28P,2R,2.0mm,STRAIGHT,SN,NTR,30x9.6x10.
6mm
1 PC
DB27-00063A FT100 COIL CHOKE 16mH,2.3A,13.0x10.0mm,Mn-Zn,4P,DIP 1 PC
DB27-00102A L320 COIL CHOKE 1.0mH,2.5A,8.4x3.4,Mn-Zn,4,DIP 1 PC
DB94-08038A ASSY PCB AUTO
MAIN,QMD RAC AR9500T,142x121mm,Y,220V-
240V,5V,12V,17V,10W,PF1-RAC,485 INV,DLX,DB92-
04839A
1 PC
2003-002212 R108 R-METAL OXIDE(S) 75Kohm,5%,2W,AF,TP,3.9x10mm 1 PC
2201-002709 C109 C-CERAMIC,DISC 0.033nF,5%,1000V,SL,TP,6.3x5mm,5mm 1 PC
2202-002252 C107 C-CERAMIC,MLC-RADIAL 1nF,10%,1000V,R,9.0x6.0x5.0mm 1 PC
2401-000480 CE900 C-AL 10uF,20%,50V,GP,TP,5x11mm,5mm 1 PC
2401-000481 CE108 C-AL 10uF,20%,50V,WT,TP,5x11mm,5mm 1 PC
2401-001573 CE107 C-AL 47uF,20%,50V,GP,TP,6.3x11mm,2.5mm 1 PC
2401-001573 CE123 C-AL 47uF,20%,50V,GP,TP,6.3x11mm,2.5mm 1 PC
6. Electrical Parts List
