Samsung AR09TXFYAWKNEU - Page 37

37
Parts Code Design Loc Parts Description Spec. Quantity Unit
2401-001573 CE902 C-AL 47uF,20%,50V,GP,TP,6.3x11mm,2.5mm 1 PC
2401-001838 CE105 C-AL 470uF,20%,25V,WT,TP,10x16mm,5mm 1 PC
2401-003607 CE106 C-AL 10uF,20%,50V,HR,TP,5x11mm,5mm 1 PC
DB94-08039A ASSY PCB SMD
MAIN,QMD RAC AR9500T,142x121mm,Y,220V-
240V,5V,12V,17V,10W,PF1-RAC,485 INV,DLX,DB92-
04839A
1 PC
DC26-00053A TRAN101 TRANS SWITCHING
AC85-265V,500mA,400mA,400mA,5V,12V,15V,S/W
TRANS,15W,EE2218
1 PC
