Samsung CL29K5MQ2X User Manual

Alignment & Adjustment
3-4 Samsung Electronics
3. Deflection(NTSC 60Hz)
4. Deflection(PAL N 50Hz)
No Item Var./Fixed
Model
CL29M16MQ CL29M2MQ
CL29M21FQ
CL29T21FQ
1 V Amp Var. 47 47 47
2 V Shift Var. 24 24 24
3 H EW Var. 48 48 48
4 H Shift Var. 49 49 49
5 V Linearity Var. 30 30 30
6 V S-Correction Fixed 32 32 32
7 V Slope Fixed 30 30 30
8 V Scroll Fixed 25 25 25
9 V Zoom Fixed 48 48 48
10 H Parabola Var. 45 45 45
11 Upper Corner Var. 51 51 51
12 Lower Corner Var. 54 54 54
13 H Trapezium Var. 22 22 22
14 Bow Var. 26 26 26
15 Angle Var. 29 29 29
No Item Var./Fixed
Model
CL29M16MQ CL29M2MQ
CL29M21FQ
CL29T21FQ
1 V
Amp
Var. 0 0 0
2 V Shift Var. 0 0 0
3 H EW Var. 0 0 0
4 H Shift Var. -6 -6 -6
5 V Linearity Fixed 0 0 0
6 V S-Correction Fixed 0 0 0
7 V Slope Fixed 0 0 0
8 V Scroll Fixed 0 0 0
9 V Zoom Fixed 0 0 0
10 H Parabola Fixed 0 0 0
11 Upper Corner Fixed 0 0 0
12 Lower Corner Fixed 0 0 0
13 H Trapezium Fixed 0 0 0
14 Bow Fixed 0 0 0
15 Angle Fixed 0 0 0
