Wiring Diagram
8-2 Samsung Electronics
8-2 Pin Connection
CN901
Pin N O. Pin N ame
1STD-LED
2TIME-LED
3GND
4VCC
5I.R
CN902
Pin N O. Pin Name
1KEY-IN2
2KEY-IN1
3GND
4KEY-IN3
CN503
Pin N O. Pin Name
1B-OUT
2G-OUT
3R-OUT
4GND
5SENSE
6GND
7N.C
8GND
9GND
10 N.C
11 GND
12 HEAT ER
13 N.C
14 B+ 200V
CN701
Pin N O. Pin N ame
1AV2-R-IN
2AV2-L-IN
3AV2-L-OUT
4AV2-R-OUT
5GND
6 AV2-V-IN
7GND
8 AV2-V-OUT
CN702
PinNO. PinName
1C-OUT
2GND
3Y-OUT
4GND
5C-IN
6GND
7Y-IN
TU01S
TU02S
CN501A
Pin N O. Pin N ame
1GND
2N.C
3GND
4HEATER
5N.C
6B+200V
CN502
Pin N O. Pin Name
1B-OUT
2G-OUT
3R-OUT
4GND
5SENSE
6GND
7N.C
8GND
FN01
PinNO. PinName
1TILTOUT
2TILTOUT
3GND
4GND
CN601
Pin
NO.
Pin N ame
1R+OUT
2R-OUT
3L+OUT
4L-OUT
CN900
Pin N O. Pin Name
1SCL
2GND
3B+3.3V
4SDA
PIP MODULE
CNP01 CNP02
CNP01
Pin N O. Pin Name
1B+8V
2B+5V
3GND
4SCL
5SDA
6GND
7H-SYNC
8V-SYNC
9PIP-F/B
10 PIP- B
11 PIP- G
12 PIP- R
CNP02
Pin N O. Pin Name
1OSD-R
2OSD-G
3OSD-B
4OSD-F/B
5
SU b-
CVBS
6GND
7
PIP-
CVBS
8N.C
