ATTACHING THE TOROIDAL FERRITE CORE TO THE POWER CORD
OF THE SUBWOOFER
If you attach a Toroidal ferrite core to the power cord of the
Subwoofer, it will help to prevent RF interference from radio signals.
1. Pull the fixing tab of the Toroidal ferrite core to open it.
2. Make two loops in the power cable of the subwoofer.
3. Attach the Toroidal ferrite core to the Subwoofer power cord as the
figure shows and press it until it clicks.
HDMI IN 1 HDMI IN 2 HDMI OUT
ID SET
DIGITAL
AUDIO IN
(OPTICAL)
AUX IN
U S B
ON
OFF
INSTALLING TOROIDAL FERRITE TO SUBWOOFER
Lift up to release the lock and open the core.
Make two rounds on the coil with the power cable.
(Start winding at 5-10cm away from the switch).
Close the lock back.
