Samsung IL020F - Remote Control (SBB-IS08 E Model Only); Cable Connection


Remote Control (SBB-IS08E model only)
Cable Connection
LAN Cable
 Pin assignment
1 2 3 4 5 6 7 8
Pin No Standard Color Signal
1 White and orange 
2 Orange TX-
 White and green 
4 Blue NC
5  NC
6  RX-
7  NC
8  NC
 Connector : RJ45
Direct LAN cable (PC to HUB)
RJ45 RJ45 MDC
HUB
P1
P1P2
P2
Signal
P1 P2 Signal

1 <--------> 1 
TX-
2 <--------> 2 TX-

 <-------->  
RX-
6 <--------> 6 RX-
