Connecting to cabinets

Connect SBB-IS08E to an external device, and then connect it to IL015E, IL020F, IL025E,
IS015F, IS020F or IS025F devices.

Connecting parts may differ in different products.
 

 
steps.
HDBT 
Connection 1
Connecting HDBT cables
HDBT OUT HDBT IN
HDBT IN HDBT OUT
 SBB-IS08E
Connection 2-1
Connecting DP cables for redundancy
DP OUT
DP IN
HDBT OUT
HDBT IN
 SBB-IS08E
 If another display is connected to the DP OUT
properly.
 

