16
Power control
 Function

 
Header Command ID Data length Checksum
0xAA 0x11 0
 
Header Command ID Data length Data Checksum
0xAA 0x11 1 



 Ack
Header Command ID Data length  r-CMD Val1 Checksum
0xAA 0xFF  'A' 0x11 

 Nak
Header Command ID Data length  r-CMD Val1 Checksum
0xAA 0xFF  'N' 0x11 "ERR"

Input source control
 Function

 
Header Command ID Data length Checksum
0xAA 0x14 0
 Setting the input source (Set Input Source)
Header Command ID Data length Data Checksum
0xAA 0x14 1 "Input Source"

0x0C Input source
0x20 MagicInfo
0x1F DVI_video
0x21 HDMI1
0x22 HDMI1_PC
0x25 DisplayPort




This model does not support HDMI1 and HDMI1_PC.

MagicInfoMagicInfo function.
