Samsung MAX-445 - Page 37

SR17,23 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X 11018-877-104
SR16,22 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X 11018-877-124
SR28 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-183
SR27 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-272
SR32,34 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3 11018-877-221
SR18,24,29,30,39,41 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-223
SR26,42 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X 11018-877-392
SR3,4,5,7,8,12 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3. 11018-877-330
SR13 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3 11018-877-471
SR19,25,40 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-473
SR15,38 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3 11018-877-821
SR20,21 2001-001000 R-CARBON;82KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-823
SC14 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25 11448-010-223
SC22 2301-000442 C-FILM,PEF;4.7NF,10%,50V,5.5X7X3MM,
SC2,3 2401-001887 C-AL;100NF,20%,50V,-,4X7MM,5,TP
SC4,5 2401-001919 C-AL;2.2UF,20%,50V,-,4X7MM,5,TP
SC11 2401-001968 C-AL;470NF,20%,50V,GP,5X11MM,5,TP
USE ONLY MAX-445(POWER AMP PARTS)
RD14,15 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO 12169-201-140
AIC101 1201-000327 IC-POWER AMP;4121,SIP,18P,-,-,-,PLA 12119-208-500
RR13,14 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4 11018-377-220
RR2 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6 11018-277-471
AR125L,125R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-222
ZR3L,3R 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3 11018-877-221
RR11,12 2001-000611 R-CARBON;3.9KOHM,5%,1/4W,AA,TP,2.4X 11018-277-392
RR10 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-472
RR5 2003-000650 R-METAL OXIDE(S);330OHM,5%,2W,AA,TP 11048-577-331
RC2,3 2401-001928 C-AL;2200UF,20%,35V,GP,16X31MM,7.5M 11607-105-222
RC7 2401-003116 C-AL;4700UF,20%,35V,-,18X35.5,7.5,B
PCW1 3711-001137 CONNECTOR-HEADER;BOX,8P,1R,2MM,STRA 13349-119-080
RCON1 AH39-20515A LEAD CONNECTOR-ASSY;-,5264,51088,8P
HEAT-SINK AH62-30017A HEAT SINK;AL,-,-,-,-,-,MAX445,- 11122-0073-00
Electrical Parts List
Loc No. New Code No. Description Specification Old Code No.
8-6 Samsung Electronics
TUNER OPTION PARTS(T/L-BAND)
FR13 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-183
FR14 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-223
BC3 2201-000247 C-CERAMIC,DISC;15PF,5%,50V,NPO,4X3. 11407-057-150
BC26 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25 11448-010-223
ICF3 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ 14529-301-753
FJ1 3716-000201 TERMINAL-BLOCK;NON SOLDER,4P,4MM,-, A3059-0006
BL1 AH27-80060A COIL-OSC;RBW07VB,345UH,AM+RF
FP1 AH40-10025A TUNER-FM;FTA4-551H,4G,75OHM
