Electrical Parts List
Loc No. New Code No. Description Specification Old Code No.
Samsung Electronics 8-7
USE ONLY MAX455(POWER AMP PARTS)
FFQ2 0501-000398 TR-SMALL SIGNAL;KSC945-Y,NPN,250MW, 12149-301-900
FFQ1 0502-000241 TR-POWER;KSA614,PNP,25W,TO-220,BK,4 12139-103-560
AIC102 1201-000192 IC-OP AMP;4558,SIP,9P,-,DUAL,20V/MV 12119-401-630
AIC101 1201-000328 IC-POWER AMP;4141,SIP,18P,-,-,-,PLA 12119-208-080
RR5,PIPE 13954-100-310 CERAMIC-PIPE;PI1.4 15MM WHT
THERMISTOR 1404-000172 THERMISTOR-NTC;100OHM,-,-,-,BK
RR11 2001-000052 R-CARBON(S);3.3KOHM,5%,1/2W,AA,TP,2 11018-377-332
RR12 2001-000060 R-CARBON;6.8KOHM,5%,1/4W,AA,TP,2.4X 11018-277-682
RR2 2001-000116 R-CARBON;820OHM,5%,1/4W,AA,TP,2.4X6 11018-277-821
AR202L,202R 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X 11018-877-152
AR204 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 11018-877-101
AR201L,201R 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-103
ZR3L,3R 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3 11018-877-151
AR125L,125R 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3. 11018-877-102
AR203L,203R,FFR4 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-222
FFR1 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-223
RR10,FFR3 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X 11018-877-392
FFR2 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-472
RR5 2003-000703 R-METAL OXIDE(S);470OHM,5%,3W,AA,TP
FFR5 2003-000710 R-METAL OXIDE(S);47OHM,5%,2W,AA,TP, 11048-577-470
FFC1 2401-000871 C-AL;220UF,20%,50V,GP,10X16MM,5MM, 11609-402-300
RC2,3 2401-001067 C-AL;3300UF,20%,42V,GP,18*35.5,7.5M 11609-116-332
BC20 2401-001975 C-AL;47UF,20%,16V,GP,5X11MM,5,TP
RC7 2401-003116 C-AL;4700UF,20%,35V,-,18X35.5,7.5,B
FFCW3 3711-000820 CONNECTOR-HEADER;BOX,2P,1R,2.5MM,ST 13349-512-561
PCW1 3711-001137 CONNECTOR-HEADER;BOX,8P,1R,2MM,STRA 13349-119-080
PJW3 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,
FFIC3 AH14-10003E IC;KIA7812PI,-,TO-220
FAN AH31-10020A FAN-DC;D0620B-12M,12VDC/0.16A, A3070-0112
FFCW2 AH39-20008M LEAD-CONNECTOR ASS’Y;5264,5395,2P,1 13078-472-115
FFCW5 AH39-20019M LEAD-CONNECTOR ASS’Y;5051,5395,3P,2 16439-0124-00
RCON1 AH39-20514A LEAD CONNECTOR-ASSY;-,5264,51088,10
HEAT-SINK AH62-30017A HEAT SINK;AL,-,-,-,-,-,MAX445,- 11122-0073-00
TUNER OPTION PARTS(L-BAND)
FR13 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3
FR14 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3
BC3 2201-000223 C-CERAMIC,DISC;12PF,5%,50V,NPO,
AC116L,116R 2201-000381 C-CERAMIC,DISC;22NF,20%,50V,Y5V,8.0
AC115L,115R,116L,116R 2201-000547 C-CERAMIC,DISC;4.7NF,20%,500V,Y5T,
AC117L,117R 2201-000783 C-CERAMIC,DISC;100NF,+80%,-20%,50V
AC122,123 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P
BC26 2301-000411 C-FILM,PEF;220NF,5%,50V,-,-,BK
TUNER LOCATION-N 2401-001975 C-AL;47UF,20%,16V,GP,5X11MM
AJW1,2 2701-000111 INDUCTOR-AXIAL;100UH,10%,2.5X3.4MM
ICF2,3 2903-000102 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ
FJ1 3716-000198 TERMINAL-BLOCK;NON SOLDER,3P,4MM
IL1 AH27-10001K COIL-CHOKE;10MH,K,Q10,-,-,CL-3
BL1 AH27-80060B COIL-OSC;RBQ-07VB,393UH,MW/LW-RF
AL101L.101R,RJW36,37 AH27-90001A COIL-SPRING;2.2UH,-,-,SPRING
