Electrical Parts List
Loc No. New Code No. Description Specification Old Code No.
8-8 Samsung Electronics
FP1 AH40-10025E TUNER-FM;FTA4-460H,4G,750HM
AJ1 AH63-40009A SHIELD-PLATE;TE-SBC,T0.3,-,SCM8100L
AH90-10619A ASS’Y-PCB FRONT ; MAX445/455
UD1,2,3,4,50,51,53 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,5
UD40,41,42,43,55,56
UZD1 0403-000344 DIODE-ZENER;UZ3.9B,3.9V,3.7-4.1V,50 12169-403-490
UQ9 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800MW, 12149-101-560
UQ1,10 0501-000398 TR-SMALL SIGNAL;KSC945-Y,NPN,250MW, 12149-301-900
UQ30,31,32 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K-22 12159-301-780
UQ17 0504-000121 TR-DIGITAL;KSR1007,NPN,300MW,22K-47 12159-301-800
UQ3,4,5,6,7,8,11,12,16 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300MW,4.7K, 12159-301-790
UQ2 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K-22
UD16,17,18,19,22,23 0601-000141 LED;ROUND,GRN,3.1MM,555NM A4150-0290
UD5,6,7,26,27,28,29,30,31
UD20,21,24 0601-000185 LED;ROUND,ORG,3.1MM,610NM A4150-0288
UD38 0601-000245 LED;ROUND,RED,3.1MM,650NM 12309-001-450
UR82,84,86,97 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3 11018-877-331
UR26,27,36,37 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X 11018-877-152
UR61,62,63 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X 11018-877-104
UR5,6,7,8,51,52,53,54 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-103
UR55,56,57,58,59,60,65
UR66,68
UR73 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3 11018-877-121
UR71,72,74,46,47,48 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3 11018-877-151
UR98 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3
UR24,25,34,35,79 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3. 11018-877-102
UR15,16,17,18,106
UR1,11,12,13,14,28,38 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-222
UR69,70,99,107,108,109
UR110,111,112,113,105
UR19,20,100,101,102
UR103,104
UR29,39 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-272
UR3 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP,1.8X 11018-877-224
UR64 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3 11018-877-271
UR30,40 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X 11018-877-332
UR50 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X 11018-877-392
UR87,88,89,90,91,92 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-472
UR95,96,81,2,93,94
UR80 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-473
UR4 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3. 11018-877-470
UR83,85 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3 11018-877-561
UR49 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X 11018-877-682
UR21,31 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3 11018-877-681
UR22,23,32,33 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3 11018-877-821
UC13,14 2201-000247 C-CERAMIC,DISC;15PF,5%,50V,NPO,4X3. 11407-057-150
UC7,8 2201-000423 C-CERAMIC,DISC;27PF,5%,50V,NPO,5.0X 11407-057-270
UC2,11,12,15,22,24,9 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12. 11417-344-473
UC32,33,35,36,37,38,39 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25 11448-010-223
UC10,40 2401-000240 C-AL;100UF,20%,10V,GP,6*11MM,5MM,TP 11608-102-104
UC5 2401-000778 C-AL;220UF,20%,10V,GP,6.3X11,2.5MM, 11608-102-224
UC20 2401-001572 C-AL;47UF,20%,50V,GP,6.3*11,2.5MM, 11608-106-470
UC21,23 2401-001904 C-AL;10UF,20%,16V,-,4X7MM,5,TP
