Electrical Parts List
Loc No. New Code No. Description Specification Old Code No.
Samsung Electronics 8-9
UC19 2401-001912 C-AL;1UF,20%,50V,GP,5X11MM,2MM,BK
UC4 2401-001931 C-AL;220NF,20%,50V,-,4X7MM,5,TP
UC1,53,54 2401-001952 C-AL;4.7UF,20%,50V,-,4X7MM,5,TP
UC6 2409-000123 C-EDL;47000UF,4UA,5.5V,-,-,5MM,BK B1104-0540
UX1 2801-001382 CRYSTAL-UNIT;12MHZ,50PPM,28-AAM,10P A1280-0017
UX2 2801-001394 CRYSTAL-UNIT;32.768KHZ,20PPM,28-AAY 14539-502-350
UVR1,2 3406-000162 SWITCH-ROTARY;5V,50MA,SPDT,20MM A3012-0018
UCW3 3708-000303 CONNECTOR-FPC/FC/PIC;6P,1.25MM,STRA B6010-0352
UCW3-1 3708-000448 CONNECTOR-FPC/FC/PIC;6P,1.25MM,STRA B6010-1610
UCW4 3708-001033 CONNECTOR-FPC/FC/PIC;22P,1.25MM,STR
UCW1 3711-003104 CONNECTOR-HEADER;NOWALL,22P,1R,1.25
UCW3-UCW3-1 3809-000199 CABLE-FLAT;30V,80C,300MM,6P,1.25MM, B6032-0072
FLT1 AH07-20045C VF-DISPLAY;SVA-10SS06,-,104.14X25,M
UIC1 AH09-10004H IC-MCU;LC866224-5D66,-,QFP,-,- B4002-0867
UIC2 AH14-10004M IC;NJU3713G,SOP,TAPE 18P
UE1 AH59-60001J MODULE-REMOCON;GP1U271R,38KHZ,-,MES B1294-0043
FLT-HOLDER AH61-20080A HOLDER-FLT;ABS,94HB,BLK,-,SCM-7450, 13322-0146-00
UD11,8 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,5
UCW2(OPTION) 3711-003097 CONNECTOR-HEADER;NOWALL,10P,1R,1.25
AH90-10649B ASS’Y PCB POWER ; MAX445
RD2 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-4 A4104-0053
RR15 2008-000001 R-FUSIBLE;1OHM,5%,1/4W,AA,TP,2.6X6. 11058-277-109
PSC1,2 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC 11469-501-070
RC4 2401-002168 C-AL;100UF,0.2,50V,GP,10X12.5,5MM,T
RF3 3601-000248 FUSE-FERRULE;250V,2A,TIME LAG,GLASS 14709-241-250
RF3 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM 13164-101-913
PSCW1 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM 13349-156-020
RCW1 3711-001128 CONNECTOR-HEADER;BOX,8P,1R,2.5MM,AN 13349-102-080
PL1,2 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7. 12429-010-330
RF1(OPTION) 3601-000304 FUSE-FERRULE;250V,630MA,TIME LAG,GL 14709-241-160
RF2(OPTION) 3601-000162 FUSE-FERRULE;250V,1.25A TIME LAG,GL
RF1(OPTION) 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM 13164-101-913
P/T(OPTION) AH26-80140C TRANS-POWER;EI66X45,115/230V,60/50H
P/T(OPTION) AH26-80140U TRANS-POWER;EI66X45,110/220V 60/50HZ
POWER-CORD(OPTION) AH39-10002L POWER CORD;CP2,KLCE-2F,2.15M,5239,V A6006-0187
POWER-CORD(OPTION) AH39-10002F POWER-CORD;BS,GTBS-2F,2.5M,5239,BS
POWER-CORD(OPTION) AH39-10001S POWER-CORD;EP2,STP#2/18,2M,SOLDERING
VSW1(OPTION) 3408-000163 SWITCH-SLIDE;250V,3A,SPDT
VSW1(OPTION) 3408-000165 SWITCH-SLIDE;250V,3A,SPDT
