AH90-10620A ASS’Y PCB POWER ; MAX455
RD1,5 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-4 A4104-0053
RR15 2008-000001 R-FUSIBLE;1OHM,5%,1/4W,AA,TP,2.6X6. 11058-277-109
PSC1,2 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC 11469-501-070
RC4 2401-002168 C-AL;100UF,0.2,50V,GP,10X12.5,5MM,T
RF3,4 3601-000248 FUSE-FERRULE;250V,2A,TIME LAG,GLASS 14709-241-250
RF3,4/HOLDER 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM 13164-101-913
PSCW1 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM 13349-156-020
RCW1 3711-000586 CONNECTOR-HEADER;BOX,10P,1R,2.5MM,A A6010-0388
RCW2 3711-000814 CONNECTOR-HEADER;BOX,2P,1R,2.5MM,AN 13349-511-573
PL1,2 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7. 12429-010-330
RF2(OPTION) 3601-000248 FUSE-FERRULE;250V,2A,TIME LAG,GLASS
RF1(OPTION) 3601-000207 FUSE-FERRULE;250V,1A,TIME LAG,GLASS 14709-241-200
RF1(OPTION) 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM 13164-101-913
P/T(OPTION) AH26-80140D TRANS-POWER;EI74X52,220V,60/50HZ,MA
POWER-CORD(OPTION) AH39-10002L POWER CORD;CP2,KLCE-2F,2.15M,5239,V A6006-0187
P/T(OPTION) AH26-80141C TRANS-POWER ; EI74X52 115/230V 60/50HZ
Electrical Parts List
Loc No. New Code No. Description Specification Old Code No.
8-10 Samsung Electronics
