DC11,19 2203-000260 C-CERAMIC,CHIP;10NF,10%,50V,X7R,201 11129-004-103
FC14,15,16,17 2203-000347 C-CERAMIC,CHIP;150NF,10%,50V,NPO,20 A1100-0988
TC43 2203-000408 C-CERAMIC,CHIP;180PF,5%,50V,NPO,201 11129-008-181
DC14,18,TC36,37 2203-000495 C-CERAMIC,CHIP;2.2NF,10%,50V,X7R,20 11129-004-222
HC5,8,FC1,2,3,4 2203-000595 C-CERAMIC,CHIP;220PF,5%,50V,NPO,201 11129-001-221
TC4,14,40 2203-000609 C-CERAMIC,CHIP;22NF,10%,50V,X7R,201 11129-004-223
TC3 2203-000648 C-CERAMIC,CHIP;24PF,5%,50V,NPO,2012 11129-009-240
FC24,25 2203-000787 C-CERAMIC,CHIP;330PF,5%,50V,NPO,201
TC22,23 2203-000802 C-CERAMIC,CHIP;33NF,10%,50V,X7R,201 11129-001-333
PC3,4,8,9,10,17,19,20 2203-000844 C-CERAMIC,CHIP;39NF,10%,50V,X7R,201 11129-019-393
TC19 2203-000891 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,20 11129-012-472
DC12,16 2203-000925 C-CERAMIC,CHIP;470NF,+80-20%,50V,Y5 11128-018-474
DC24 2203-000953 C-CERAMIC,CHIP;470PF,5%,50V,NPO,201 11129-004-471
TC13,41,29 2203-000979 C-CERAMIC,CHIP;47NF,10%,50V,X7R,201
DC22,DC15,TC2 2203-001137 C-CERAMIC,CHIP;68NF,+80-20%,50V,Y5V 11129-004-683
TC20 2203-001223 C-CERAMIC,CHIP;820PF,10%,50V,X7R,20 A1100-0023
TC44,16 2203-001517 C-CERAMIC,CHIP;15PF,5%,50V,NPO,2012
DC20,21 2203-001524 C-CERAMIC,CHIP;47PF,5%,50V,NPO,2012
TC10,EC25 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,2012
DC23 2203-001550 C-CERAMIC,CHIP;1.2NF,10%,50V,X7R,20
FC12,13 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,20
TC17 2203-001611 C-CERAMIC,CHIP;22PF,5%,50V,NPO,2012
EC4 2301-000449 C-FILM,PEF;47NF,10%,50V,8X11X4.5MM,
EC7,17,TC12,27 2401-000419 C-AL;10UF,20%,16V,GP,5X11,5,-
TC33 2401-000438 C-AL;10UF,20%,25V,GP,5*11,2MM, 11608-104-103
EC28,29 2401-000459 C-AL;10UF,20%,35V,GP,5*7,2MM,TP 11608-155-103
TC24 2401-000795 C-AL;220UF,20%,16V,GP,8X11.5,3.5MM,
PC12,TC45 2401-001019 C-AL;3.3UF,20%,50V,GP,4X7,1.5MM,
PC13 2401-001413 C-AL;470UF,20%,35V,GP,10X20,5MM, 11609-402-130
HC1,2 2401-001538 C-AL;47UF,20%,25V,GP,6X11,2.5MM,-
EC11,22,VC1,KC22 2401-001895 C-AL;100UF,20%,16V,GP,6.3X11MM,2.5M
DC7,8,9,10,EC8 2401-001912 C-AL;1UF,20%,50V,GP,5X11MM,2MM,BK
EC14 2401-001917 C-AL;1UF,20%,6.3V,-,4X7MM,5,TP
HC3,4,TC21,31,32,34,35
EC9,10,12,13 2401-001919 C-AL;2.2UF,20%,50V,-,4X7MM,5,TP
FC6,7,9
FC5,10,11,18,19
EC15,16
FC22,23 2401-001938 C-AL;22UF,20%,25V,GP,5X11MM,2MM,BK
DC1,2,3,5 2401-001940 C-AL;3.3UF,20%,50V,LL,5X11MM,5MM,TP 11608-306-332
PC14 2401-001942 C-AL;3300UF,20%,35V,GP,18X35.5MM,7. 11607-105-332
PC5 2401-001945 C-AL;330UF,20%,50V,GP,10X20MM,5MM,B 11607-106-331
PC11,15,16,EC6,19 2401-001954 C-AL;4.7UF,20%,50V,GP,5X11MM,5,TP
TC25,26
EC3,5,23,24,FC20,21 2401-001955 C-AL;4.7UF,20%,50V,LL,5X11MM,5MM,TP 11608-306-472
TC30 2401-001968 C-AL;470NF,20%,50V,GP,5X11MM,5,TP
DC25,26,TC15 2401-001975 C-AL;47UF,20%,16V,GP,5X11MM,5,TP
FC8,TC18,PC6,7
PC18,TC42
VC4 2401-001990 C-AL;10UF,20%,25V,BP,5X11MM,5MM,TP 11608-204-100
Loc No. New Part No. Description Specification Old Part No.
Electrical Parts List
Samsung Electronics 8-3
