TC7 2404-000250 C-TA,CHIP;470NF,20%,25V,-,3216,-,TP
HL1,2,3 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.4MM 12429-411-100
TX3 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12 14539-501-140
DX1 2802-000158 RESONATOR-CERAMIC;4MHZ,0.5%,TP,10.0 14534-504-043
TX1 2802-000215 RESONATOR-CERAMIC;19KHZ,+-38HZ,-,7. 14539-504-100
TFL1,3 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ 14529-301-753
TFL4 2903-000148 FILTER-CERAMIC;BP,450KHZ+-1KHZ A1243-0049
ZCW1 3708-001045 CONNECTOR-FPC/FC/PIC;15P,1.5MM,STRA
CMW1,2 3710-000541 CONNECTOR-SOCKET;20P,-,1.25MM,STRAI
VCW1 3711-000588 CONNECTOR-HEADER;BOX,10P,1R,2.5MM,S 13349-103-103
ECW1 3711-003112 CONNECTOR-HEADER;BOX,8P,1R,2.5MM,-,
ANT-JACK 3716-000201 TERMINAL-BLOCK;NON SOLDER,4P,4MM,-, A3059-0006
SPK-JACK 3716-000204 TERMINAL-BLOCK;NON SOLDER,4P,11MM,- A3059-0017
EJACK1,HJACK1 3722-000363 JACK-PHONE;9P,6.4MM,AU,BLK,- A3040-0115
FJACK1 3722-000383 JACK-RCA;6P/4C,3.5MM,SN,BLK,#16~22 A3040-0241
DIC1 AH14-10007E IC;M65846FP,SOP,STICK DSP/ECHO
EIC1 AH14-10007F IC;M62453SP,DIP,STICK VOCAL FADER/M
TIC2 AH14-10007G IC;LC72131,DIP,STICK PLL
TIC1 AH14-10007H IC;LA1836,DIP,STICK IF+MPX
TFL5,6 AH26-10001A TRANS-IF;FV-AD-BASE19K/38K,LOW PASS 12450-304-040
TL1 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,- 12619-030-005
TL2 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,1
TML1 AH27-80060A COIL-OSC;RBW07VB,345UH,AM+RF
PW1 AH39-20514A LEAD CONNECTOR-ASSY;-,5264,51088,10
R-Z CONNECTOR AH39-20529A LEAD CONNECTOR-ASSY;-,52305,51044,2
EW1 AH39-20542A LEAD CONNECTOR-ASSY;-,5264,51088,8P
VW1 AH39-20543A LEAD CONNECTOR-ASSY;-,5264,51088,10
TO CHASSIS ANT AH39-50001H LEAD-FASTEN;RING,1007#24,100MM,BLK 13059-201-103
FEDP AH40-10025A TUNER-FM;FTA4-551H,4G,75OHM
AH62-30060A HEAT SINK-CD;AL,-,T1.0,-,-,-,SCM-70 15684-505-820
HEATSINK AH62-30064D HEAT SINK;DAT7000,AL,-,ANODIZING,BL 15684-509-730
AH62-30100A HEAT SINK-M;-,ALS,-,-,-,-,-,MAX670R
AH62-30117A HEAT SINK-TR;-,ALS,-,T2.0,-,-,-,MAX
SZD1,2 0403-000374 DIODE-ZENER;UZ9.1BSC,9.1V,8.89-9.29 12169-404-840
SQ2 0504-000146 TR-DIGITAL;-,PNP,300MW,47K-47K,TO-9 12159-301-760
SQ1,3 0504-000203 TR-DIGITAL;-,NPN,300MW,47K-47K,TO-9
SIC2 1001-000111 IC-ANALOG SWITCH;GD4066B,BILATERAL
SIC1 1201-000463 IC-OP AMP;074,SOP,14P,196MIL,SINGLE
SR43 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3 11018-877-561
SR42 2003-000502 R-METAL OXIDE(S);150OHM,5%,2W,AA,TP 11048-577-151
SR35,37 2007-000001 R-CHIP;68KOHM,5%,1/10W,DA,TP,2012 11119-101-683
SR41,15 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012 11119-101-561
SR23 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012 11119-101-152
SR34,18 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012 11119-101-124
SR17 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012 11119-101-153
SR30 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012 11119-101-183
SR6,8 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 11119-101-102
SR19,31,39 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012 11119-101-221
SR5,7,24,10 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012 11119-101-223
SR29,1,2 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012 11119-101-273
Loc No. New Part No. Description Specification Old Part No.
Electrical Parts List
8-4 Samsung Electronics
