AH90-10716P ASSY-FRONT PCB;MAX670R/CHN,EXP 230V
UD2,3 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,5
UD1,4,14 0402-000125 DIODE-RECTIFIER;1N4001,50V,1A,DO-41 A4104-0001
UZD2 0403-000355 DIODE-ZENER;UZ5.1BSB,5.1V,4.97-5.18 12169-404-780
UZD1 0403-000394 DIODE-ZENER;UZP5.6B,5.6V,5.2-6.0V,1 12169-404-110
UQ9 0501-000319 TR-SMALL SIGNAL;-,PNP,1W,TO-92L,TP, 12149-101-590
UQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250MW,TO 12149-301-900
UQ2 0504-000117 TR-DIGITAL;-,NPN,300MW,10K-10K,TO-9 12159-301-840
UQ7,8,11 0504-000144 TR-DIGITAL;KSR2002,PNP,300MW,10K-10 12159-301-340
UQ4,5,6,10 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K-22
ULD15 0601-000245 LED;ROUND,RED,3.1MM,650NM 12309-001-450
ULD1,2,3,4,5,6,7 0601-001051 LED;ROUND,GRN/RED,3.2MM,563/650NM
ULD8,9,10,11,12,13,14
UIC4 1201-000163 IC-OP AMP;4560,SOP,8P,150MIL,DUAL,1 12119-401-300
UIC2 1204-000156 IC-EQUALIZER;BA3834S,DIP,18P,-,PLAS B4012-0447
UR22 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-153
UR15,17 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X 11018-877-152
UR59 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X 11018-877-104
UR12,13,24,25,26,79,80 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-103
UR72,73,74,75,76,77,78
UR65,66,67,68,69,70,71
UR101,128
UR14,112,113,114 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3. 11018-877-102
UR116,121
UR18,62,63 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-222
UR19 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-272
UR5 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP,1.8X 11018-877-224
UR85,64 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-223
UR84 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3 11018-877-271
UR23 2001-000660 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3. 11018-877-333
UR20,32,UJW15 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-472
UR33 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X 11018-877-682
UR21 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-822
UR119 2003-000513 R-METAL OXIDE(S);15OHM,5%,1W,AA,TP, 11048-477-150
UJW84,85,87,93,UR122 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 11119-101-000
UJW76,77,78,79,80,81 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 11118-001-000
UJW82,83,86
UR103 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012 11119-101-122
UR57,58,35,36 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012 11119-101-152
UR106 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 11119-101-104
UR104,105 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 11119-101-103
UR102 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012 11119-101-123
UR95,96,97 2007-000449 R-CHIP;180OHM,5%,1/10W,DA,TP,2012 11119-101-181
UR1,2,3,4,6,7,8,9,10 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 11119-101-102
UR34,39,111,118,127
UR124,125
UR126,123 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 11119-101-102
UR31,37 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012 11119-101-222
UR38,98 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012 11119-101-272
UR11,92,93,94,86,87,88 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012 11119-101-221
