UR27,28,29,30,45,46 2007-000642 R-CHIP;270OHM,5%,1/10W,DA,TP,2012 11119-101-270
UR47,48,51
UR52,55,56,89,90,91
UR49,50,53,54 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012 11119-101-391
UR40,42,99,108 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012 11119-101-472
UR41 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012 11119-101-682
UR107 2007-001201 R-CHIP;820OHM,5%,1/10W,DA,TP,2012 11119-101-821
UC3,4 2201-000223 C-CERAMIC,DISC;12PF,5%,50V,NPO,5.0X 11407-057-120
UC1,2 2201-000423 C-CERAMIC,DISC;27PF,5%,50V,NPO,5.0X 11407-057-270
UC29,15,30 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12. 11417-344-473
UC6 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25 11448-010-223
UC43,19,7 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,0.3,50V,Y5
UC34,UC45 2203-000199 C-CERAMIC,CHIP;100NF,+80-20%,50V,Z5
UC5,31 2203-000844 C-CERAMIC,CHIP;39NF,10%,50V,X7R,201 11129-019-393
UC42 2203-001105 C-CERAMIC,CHIP;6.8NF,10%,50V,X7R,20 11129-004-682
UC35 2203-001214 C-CERAMIC,CHIP;8.2NF,10%,50V,X7R,20 11129-004-822
UC22,23,24,41 2301-000375 C-FILM,PEF;100NF,5%,50V,11X12.5X6.5 11505-713-104
UC8,13,14,20,32 2401-000244 C-AL;100UF,20%,10V,GP,6.3*7,2.5MM,T 11608-152-104
UC17,18 2401-000475 C-AL;10UF,20%,50V,GP,5*11,2MM, 11608-106-100
UC39,44 2401-000918 C-AL;22UF,20%,16V,GP,5X7,5,-
UC12 2401-001572 C-AL;47UF,20%,50V,GP,6.3*11,2.5MM, 11608-106-470
UC36,37 2401-001893 C-AL;100UF,20%,16V,-,6.3X7MM,5,TP
UC38 2401-001904 C-AL;10UF,20%,16V,-,4X7MM,5,TP
UC33 2401-001931 C-AL;220NF,20%,50V,-,4X7MM,5,TP
UC10 2401-002180 C-AL;2.2UF,0.2,50V,GP,5X11,5MM,TP
UC9 2409-000123 C-EDL;47000UF,4UA,5.5V,-,-,5MM,BK B1104-0540
UX2 2801-001382 CRYSTAL-UNIT;12MHZ,50PPM,28-AAM,10P A1280-0017
UX1 2801-001394 CRYSTAL-UNIT;32.768KHZ,20PPM,28-AAY 14539-502-350
USW1,2,3,4,5,6,7,8 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X 13559-901-100
USW9,10,11,12,13,14,15,16
USW17,18,19,20,21,22,23
USW24,25,26
USW24,25,26
USW27 3406-000162 SWITCH-ROTARY;5V,50MA,SPDT,20MM A3012-0018
CCW1,2 3711-002581 CONNECTOR-HEADER;WALL,20P,1R,1.5MM,
UIC5 AC14-12001G IC;KA78L05,T,-
VFD AH07-20045B VF-DISPLAY;SVA-16LL03,-,141.5X41.0,
UIC1 AH11-10002F IC-MASK ROM;LC86P6232,-,DIP B4000-0017
FRONT PCB AH41-10404A PCB-FRONT;MAX650R/670R,1L,PHENOL,33
REMOCON EYE AH59-60001J MODULE-REMOCON;GP1U271R,38KHZ,-,MES B1294-0043
UD13 0402-000125 DIODE-RECTIFIER;1N4001,50V,1A,DO-41 A4104-0001
UQ3 0501-000407 TR-SMALL SIGNAL;-,NPN,800MW,TO-92,- 12149-401-150
UR44 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-222
UC25 2203-000844 C-CERAMIC,CHIP;39NF,10%,50V,X7R,201 11129-019-393
UC27,28 2203-001619 C-CERAMIC,CHIP;27PF,5%,50V,NPO,2012
UC26 2401-000244 C-AL;100UF,20%,10V,GP,6.3*7,2.5MM,T 11608-152-104
UX3 2802-000158 RESONATOR-CERAMIC;4MHZ,0.5%,TP,10.0 14534-504-043
UIC3 AH09-10060H IC-MCU;MSM6656A-662RS,18P,DIP,8BITS
UD5,8 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,5
Loc No. New Part No. Description Specification Old Part No.
Electrical Parts List
Samsung Electronics 8-7
