RC1,2 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC 11469-501-070
FUSE1,3,4 3601-000248 FUSE-FERRULE;250V,2A,TIME LAG,GLASS 14709-241-250
RF1,3,4 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM 13164-101-913
RCW3 3708-001044 CONNECTOR-FPC/FC/PIC;5P,1.5MM,STRAI
RCW1 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM 13349-156-020
RCW2 3711-000588 CONNECTOR-HEADER;BOX,10P,1R,2.5MM,S 13349-103-103
RJW1,9,11,5,8 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,
POWER TRANS AH26-80140K TRANS-POWER;EI85.8X57,115/230V,60/5
RL1,2 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7. 12429-010-330
AH90-10689A ASSY-PCB MAIN;MAX670Z,CHN
JD1L,1R,2L,2R,3L,3R 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,5
CD2,3,4,6,7,8,LD1
UD1,2,3,4,6,JD5,6,RD9
RD3,4,5,10,11 0402-000125 DIODE-RECTIFIER;1N4001,50V,1A,DO-41 A4104-0001
RD1,2 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO 12169-201-140
JZD1 0403-000358 DIODE-ZENER;UZ5.6BSB,5.6V,5.46-5.7V 12169-404-790
UZD1,2 0403-000367 DIODE-ZENER;UZ7.5BSC,7.5V,7.33-7.64 12169-404-820
RZD1,3 0403-000379 DIODE-ZENER;UZP12B,12V,11.4-12.6V,1 12169-403-910
RQ9,8 0501-000010 TR-SMALL SIGNAL;KSC1008-Y,NPN,80V,6 12149-301-050
LQ1,2,RQ4 0501-000369 TR-SMALL SIGNAL;-,NPN,1W,TO-92L,-,1 12149-301-910
LQ3,CQ11,12,UQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250MW,TO 12149-301-900
CQ5,10
DQ5L,5R,UQ2,3,4,5 0501-000407 TR-SMALL SIGNAL;-,NPN,800MW,TO-92,- 12149-401-150
CQ1,6,8,3,UQ7 0501-000610 TR-SMALL SIGNAL;-,PNP,1W,TO-92L,TP,
RQ2,7 0502-000424 TR-POWER;2SB1566-F,PNP,2W,TO-220FN, B4052-0086
RQ3 0502-000425 TR-POWER;2SD2395-F,NPN,2W,TO-220FN, B4052-0087
CQ2,4,7,9 0504-000118 TR-DIGITAL;-,NPN,300MW,22K-22K,TO-9 12159-301-780
DQ1L,1R,UQ8,DQ2,UQ9
JQ4L,4R,DQ6L,6R 0504-000122 TR-DIGITAL;-,NPN,300MW,4.7K,TO-92,T 12159-301-790
JQ5,DQ3,4,7,8 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K-22
JQ2L,2R 0505-000197 FET-SILICON;2SK373Y,N,-,-,-,400MW,T B4054-0023
DIC2 1001-000111 IC-ANALOG SWITCH;GD4066B,BILATERAL
UIC4 1003-000293 IC-MOTOR DRIVER;LB1649,DIP,14P,-,-,
UIC3 1103-001006 IC-EEPROM;93LC46,64X16BIT,DIP,8P,30
DIC3 1201-000192 IC-OP AMP;4558,SIP,9P,-,DUAL,20V/MV 12119-401-630
JIC1 1201-000364 IC-PREAMP;3442A,QFP,56P,-,DUAL,-,PL B4012-0417
RIC3 1203-000242 IC-POSI.FIXED REG.;7812,TO-220,3P,- 12109-401-690
RIC4 1203-000276 IC-POSI.FIXED REG.;7805,TO-220,3P,- 12119-601-770
RIC2 1203-000282 IC-POSI.FIXED REG.;7806,TO-220,3P,- 12119-601-830
RIC1 1203-000294 IC-POSI.FIXED REG.;7808,TO-220,3P,- 12109-401-730
DIC1 1204-000134 IC-DNR PROCESSOR;KA2271B,DIP,16P,-, 12109-323-990
LR1 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP,1.8X3 11018-877-391
JR9 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-153
UR104 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4 11018-377-100
JR1L,1R,UR9,DR2,7 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X 11018-877-104
DR22L,22R
JR14,DR13,19,25,24,27 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 11018-877-101
CR1,2,9,18,19,10 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-103
CR16,20,21,UR2,3,4,JR27
Loc No. New Part No. Description Specification Old Part No.
Electrical Parts List
8-8 Samsung Electronics
To Next Page
