Samsung ML-1645

Service Manual
ExplodedView and Parts list
5-6
Samsung Electronics
Drawer# SEC_CODE DESCRIPTION QT’Y Service Grade Remark
5.2-0 JC96-05123A ELA UNIT-FRAME 1 SA A
5.2-1 JC61-02567A FRAME-BASE 1 SA A
5.2-2 JC97-02218A MEA UNIT-PLATE KNOCK_UP 1 SA A
5.2-2-1 JC61-01158A PLATE-M-KNOCK_UP 1 SA A
5.2-2-2 JC66-00720A SHAFT-P-CORE 1 SA A
5.2-2-3 JC72-01004A PMO-IDLE KNOCK UP MP 2 SA A
5.2-2-4 JC74-00011A MPR-PAD KNOCK UP MP 1 SA A
5.2-3 JC61-01258A SPRING ETC-TORSION DEVE_L 1 SA A
5.2-4 JC61-01259A SPRING ETC-TORSION DEVE_R 1 SA A
5.2-5 JC96-05018A ELA UNIT-DRIVE 1 SA A
5.2-5-1 JC61-02619A BRACKET-GEAR 1 SNA D
5.2-5-2 JC61-02577A BRACKET-MOTOR 1 SNA B
5.2-5-3 JC66-01998A GEAR-RDCN A 1 SNA B
5.2-5-4 JC31-00090B MOTOR BLDC 1 SNA A
5.2-5-5 JC66-01999A GEAR-RDCN B 1 SNA B
5.2-5-6 JC66-00806A GEAR-OPC DR 76/38/29 1 SA A
5.2-5-7 6031-000023 WASHER-PLAIN 2 SA A
5.2-6 JC97-02218A MEA UNIT-PLATE KNOCK_UP 1 SA A
5.2-7 JC70-00500C ADJUST-CASSETTE_R 1 SA A
5.2-8 JC70-00499C ADJUST-CASSETTE_L 1 SA A
5.2-9 JG66-40003A GEAR-PINION 1 SA A
5.2-10 JC61-00836A FOOT-FRONT 2 SA A
5.2-11 JC66-00807A GEAR-FUSER DR 63/35 1 SA A
5.2-12 JC66-00808A GEAR-FEED DR 41 1 SA A
5.2-13 JC66-00822A LEVER-M-ACTUATOR_EMPTY 1 SA A
5.2-14 JB61-00076A SPRING ETC-TORSION DOC (CC2-F) 1 SA A
5.2-15 JC63-00622A GROUND-P-OPC 1 SA A
5.2-16 6107-001503 SPRING-CS 2 SA A
Frame Parts List(ML-2240)
*SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
*Grade : Parts Class”A,B,C,D,E”
