Samsung ML-1645

Service Manual
ExplodedView and Parts list
5-1
Samsung Electronics
5. Exploded Views and Parts List
5.1 Main Assembly 5-2
5.2 Frame Assembly(ML-2240)
5-5
5.3 Frame Assembly(ML-1640)
5-7
5.4 Fuser Unit
5-9
5.5 Paper Path Unit
5-11
5.6 MP Tray Assembly (Only ML-2240)
5-13
Contents
Contents
LASER PRINTER The keynote of Product
- Speed
ML-1640 : 16 ppm (A4), 17 ppm( Ltr)
ML-2240 : 22ppm (A4), 23 ppm (Ltr)
- Emulation : GDI
- Processor : 150 Mhz Jupiter4e CPU
- Memory : 8 MB
- Toner cartridge : Initial (0.7K), Sales (1.5K)
- MP tray : Only ML-2240
- Interface : Full Speed USB 2.0
- Machine life : 50K (pages)
