Samsung ML-1645

Service Manual
Disassembly and Reassembly
3-7
Samsung Electronics
• Before disassembling, Separate the Main cover. (Refer to 3.3)
• Release the LSU after remove the 3 screws and 2 harness.
3.2.7 LSU
1. Remove the 5 screws. 2. Remove the 2 connector as shown below.
3.2.8 HVPS board
